MODEL

LE-2011

CHARACTERISTIC

AUTOMATIC CUTTING&SEWING

                                             SERVO MOTOR

　                                                                     3.0kw x1

SUCCESSIVE CUTTING

　HEAT SUCCESSIVE CUTTING

SEWING MACHINE

(DN-2HS) 1PCS

LAMINATED CUTTING

1PCS

APPLICABLE PLASTIC CLOTH

PP/PE WOVEN BAGS

PRODUCTION CAPACITY

28~35pcs(BAG/MIN)

CUTTING LENGTH

 550~1300 MM

CUTTING WIDTH

300~850 MM

CUTTING ACCURACY

+.-  1MM

BAG MOUTH ANTI-STUCK DEVICE

EQUIPPED

STITCHING RANGE

3.8~8 (P/MM)

DIAMETER OF UNWINDING CLOTH

1200 MM

SIDE FOLDING WIDTH

15~25MM

人力 MAN POWER

1 PERSONS

MAIN DRIVING MOTOR

AC   2HP

POWER REQUIRED

8KW

AIR COMPRESSOR

3HP X 1UNIT

DELIVERY UNIT

COUNTING STACK TYPE BELT CONVEYOR

MACHINE DIMENSION

L7880 x W3880 x H1360MM    (N.W 3250KGS)

CUBAGE  ARK

1X20"

THE SPECIFICATIONS AND SIZES MENTIONED IN THIS LEAFLET ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE
